Most of the devices i make need 7.5V DC and usualy they have + in the center (but always chack to be sure!).
I use the PSSMV1, this is also the power supply i recomended for my devices.
schele mixer front back
connection:
- 2 Composite video inputs.
- 1 Composite Video output.
controls:
- Cross fader.
- Sync selection switch.
- 2 Fade effect settings.
power consumption:
- 9V Battery.
compatibility:
- NTSC and PAL.
Built:
(w VAT) 108,90 euro
(w/o VAT) 90,- euro
Kit:
(w VAT) 39.93 euro
(w/o VAT) 33,- euro
links:
- Schele-Mixer
- Kit assembling instructions
HSS3jb PCB
HSS3jb
HSS3j.
features:
16 selectable audio/video synths
8 video synths
analog lowpass filter.
composite out, NTSC or PAL.
Connections:
- line in (can take any signal from 0V to 12V)
- line out
- midi in
- trigger out
- trigger in
- ir in
- ir out
- composite video out.
Kit with video converter:
(w VAT) 137,94 euro
(w/o VAT) 114,- euro
Aluminum back pannel:
(w VAT) 6,05 euro
(w/o VAT) 5,- euro
HSS3jb assembling instructions.
VCOFan
connection:
- Voltage controlled Volume.
- Voltage controlled Fan speed.
- Audio out.
knobs:
- Volume attenuation.
- Fan Speed attenuation.
power consumption:
- +12v (30 to 150 mA depending on Fan speed)
- - 12v is not used.
built:
(w VAT) 119,79 euro
(w/o VAT) 99,- euro
links:
- vco-fan
- big-images
analogHD2nr5
Only the PCB:
(w VAT) 14,52 euro
(w/o VAT) 12,- euro.
Kit: (hard disk not included). assembling instructions
(w VAT) 36,60 euro
(w/o VAT) 30,- euro.
More info about this device can be found here
the analog HD2s in the image are priced the following:
Build:
(w VAT) 154,88 euro
(w/o VAT) 128,- euro.
a big image can be seen here.
TinyWTR side
TinyWTR top
specs:
- 3-Bit DAC op amp buffered output.
- 512 step wavetable.
- 64 steps sequencer.
- +/- 3.7 octave range.
- set sequencer length and vibrato speed (by holding the button down during power up)
connections:
- line out (also works with headphone)
build:
(w VAT) 24,20 euro
(w/o VAT) 20,- euro
shipping:
- depends.
DEP2b assembled
DEP2b vertical jack option
(w VAT) 83,49 euro
(w/o VAT) 69,- euro
kit without potentiometers and without knobs:
(w VAT) 66,55 euro
(w/o VAT) 55,- euro
PCB with preprogramed atmega328 chip:
(w VAT) 20,57 euro
(w/o VAT) 17,- euro
build:
(w VAT) 133,10 euro
(w/o VAT) 110,- euro
build with aluminum back panel:
(w VAT) 151,25 euro
(w/o VAT) 125,- euro
shipping costs depends on country.
specs:
- 8bit DAC.
- 8bit ADC.
connections:
- 3 CV inputs (0 to 5V, clipt)
- power 9V DC minus in the center. (works best with BOSS stabilized power supply).
- audio in 1/4 jack.
- audio out 1/4 jack.
effects:
- audio threshold sample loop forward
- audio threshold sample loop forward backward
- audio threshold delay sample loop forward
- audio threshold delay sample loop forward backward
- audio threshold sample loop arpeggio pitch shift forward
- audio threshold sample loop arpeggio pitch shift forward backward
- audio threshold sample loop time stretch forward
- audio threshold sample loop time stretch forward backward
switches:
- true bypass.
- low frequency cut after DAC.
buttons:
- hold.
- feedback.
- cut audio input.
- sample now
- sample rate divide
leds:
- audio input volume.
- audio input trigger active.
potentiometers:
- (small white 1) sample rate divide.
- (small white 3) sample length or pitch sequence select.
- (small white 1) variable.
- (small yellow 1) audio threshold.
- (small blue 1) resonance low-pass filter.
- (small blue 2) low-pass filter.
- (big white 1) DAC volume.
- (big white 2) output volume.
link:
assembling instructions
documentation
HSS3j assembled only audio
HSS3j assembled
HSS3j kit
features:
16 selectable audio/video synths
8 video synths
analog lowpass filter.
composite out, NTSC or PAL.
Connections:
- line in (can take any signal from 0V to 12V)
- line out
- midi in
- trigger out
- trigger in
- ir in
- ir out
- composite video out.
Assembled only audio:
(w VAT) 121,- euro
(w/o VAT) 100,- euro
(looks like this)
(build with aluminum back panel, has all inputs and outputs but no video features).
For the only audio option you can choose between 2 options of sounds.
option A:
http://vimeo.com/10650308
http://vimeo.com/10415305
option B:
http://vimeo.com/11426693
http://vimeo.com/33896077
Assembled with video out:
(w VAT) 193,60 euro
(w/o VAT) 160,- euro
(looks like this)
(build with aluminum back panel, has all inputs and outputs including the video features).
HD Rot back
HD Rot
desc:
Rotate the wheel left and one trigger out will blink, rotate right and the other will blink.
Rotate the wheel left and the CV output will decrease rotate right and the CV output will increase, the display will show a voltage close to the voltage that is coming out.
connectors:
- CV out (about 0 to 10v via r2r DAC in 8-BIT).
- 2 Trigger out.
power:
- +12V (uses about 30 mA).
- GND
- -12V (is not used).
size:
- 111 mm wide (will have small gap between the module next to it).
built: 128,- euro.
(w VAT) 154,88 euro
(w/o VAT) 128,- euro
GVS1c assembled and backpannel
GVS1c kit
(w VAT) 66,55 euro
(w/o VAT) 55,- euro
Build:,- euro.
(w VAT) 102,85 euro
(w/o VAT) 85,- euro
Build with back panel:
(w VAT) 114,95 euro
(w/o VAT) 95,- euro
tested only to work with:
- Korg Kross Four
- Panasonic AVE5
- 1T TBC
shipping costs depends on country.
specs:
- 1 BIT video sampler
- resolution 128x96
- lowpass filter on video (for analogue/antialias look).
specs:
- PAL or NTSC.
connections:
- mono jack 3.5mm audio/trigger in
- DC +)- 9V
- composite video in RCA jack
- composite video out RCA jack
link:
- GVS1
- GVS1c manual
- GVS1c assembling instructions
